Beddelka Qalalan ee Guddaha Alxanka Soo noqnoqda ee Adag ee Gobolka

TENYES Guddaha Beddelka Qalalan ee Adag ee Alxanka Soo noqnoqda ee Gobolka waxaa lagu sameeyay Shiinaha. Shirkaddayadu waxay leedahay waayo-aragnimo qani ah oo ku saabsan soo saarista qalabka kuleylka soo noqnoqda ee soo noqnoqda. Badeecadahayadu waxay leeyihiin faa'iidooyin aan qarsoonayn xagga qiimaha iyo tayada. Inta badan Gudaheeda Transformer Solid State Frequency High Frequency u dhoofinta Koonfur-bari Aasiya, dalalka Bariga Dhexe, dalalka Afrika, Galbeedka Aasiya, Koonfurta Ameerika, Russia suuqyada. Waxaan had iyo jeer isku daynaa inaan ka helno wakiillo ka socda adduunka oo dhan si ay u iibiyaan alxankayaga.

Soo dir weydiin

Sharaxaada Alaabta

TENYES-ka Guddaha Beddelka Qalalan Alxanka Adag ee Heerka Sare ee Gobolka waxa si gaar ah loogu habeeyey alxanka tuubada tolayga toosan.

Waxay qabataa qaybaha awooda sare ee US IR IRFP460 MOSFET iyo Germany IXYS Company DSEI60-06A diode soo kabashada degdega ah. Capacitor-ka awoodda sare ee C iyo gariiradda inductor L waxay ka kooban yihiin qaabka hadda-jooga wareegga resonance sare-voltage, kaas oo aan u baahnayn wax-soo-saarka wax-soo-saarka. Sidaa darteed, ma aha oo kaliya hagaajinta waxtarka, laakiin sidoo kale waxay kordhisaa kalsoonida alxanka.

TENYES SCR Guddaha Beddelka Qalalan Hordhaca Alxanka Adag ee Gobolka

Qalabkan TENYES SCR Gudaha Qalalan Alxanleha Adag ee Soo noqnoqoshada Sare ee Gobolka waa alxanka tuubada ugu xasiloon, alxankanna wuxuu wataa dammaanad 1 sano ah. TENYES SCR Guddaha Beddelka Qalalan Alxanka Adag ee Heer Sare ee Gobolka waxa uu inta badan ka kooban yahay golaha hagaajinta, golaha beddelka (oo ay ku jiraan qaboojiyaha), console, nidaamka qaboojinta iyo beddelka-soo-dejinta. Waxaan qaadaneynaa tignoolajiyada hagaajinta dhaqanka SCR. Waxaan ku soo saari karnaa SCR Gudaha Qalalan Transformer Solid State Welder High Frequency laga bilaabo 50KW ilaa 1200KW.

TENYES SCR Guddaha Beddelka Qalalan ee Adag ee Heerka Alxanka Celceliska Sare ee Gobolka

La xakameeyey qayb	SCR toosiye
Xakamaynta habka	Waji-wareejin kicin
Wax soo saarka DC	Aan la buuxin rukun badhkii
Deggan saxnaanta danab	In ka yar in ka badan 5%
Qaboojin habka	Biyo qaboojin
Waxtarka AC-DC	In ka yar in ka badan 90%, luminta tamarta falcelinta weyn
Awood arrin	0-0.90 doorsoome, badiyaa 0.75-0.8
Wax soo saarka kala duwanaanshaha isbedbeddelka dulqaadka danab	± 10%

TENYES SCR Gudaha Gudaheeda Beddelka Qalalan ee Adag ee Alxanka Soo noqnoqoshada Sare ee Gobolka Feature iyo Codsiga

Baaxadda alxanka ee arjiga SCR Guddaha Beddelka Qalalan Alxanka Adag ee Gobolka:

Waxaa inta badan loo isticmaalaa alxanka noocyada kala duwan ee tuubooyinka birta dhaadheer sida birta kaarboon hooseeya, birta xoogga badan, birta alloy, iwm.

Beddelka Qalalan ee SCR Gudaha Alxanka Adag ee Gobolka Sifooyinka:

1. Ma jirto danab sare, ammaan, la isku halayn karo oo hufan.

2. Qaybaha ugu muhiimsan waa alaabooyinka caanka ah ee caalamiga ah, sida: IR, IXYS iyo Siemens, iwm.

3. Voltage iyo hadda wareegga xakamaynta jawaab-celinta laba-laabka ah, nidaam xasiloon, saxsanaan sare, faragelin yar.

4. The power range is stepless adjustable from 0-100%, with over-voltage, over-current and other fault protection systems.

5. Bandhiga heerka shaqadu waa dijitaal, hawlgalku waa mid fudud, dayactirkuna waa mid ku habboon.

6. Tayada alxanka ayaa wanaagsan, ballaca iyo kulaylka alxanka waa lebis.

TENYES SCR Guddaha Beddelka Qalalan ee Adag ee Gobolka Faahfaahinta Alxanka Soo noqnoqoshada Sare

Mabda'a aasaasiga ah ee SCR Inside Transformer Qalalan Alxanka Adag ee Heerka Sare ee Gobolka: ka dib marka caadiga ah ee saddexda weji ee beddelka ah ee hadda uu hoos u dhigo isbeddelka, waxay gashaa golaha hagaajinta waxayna noqotaa mid joogto ah oo toos ah oo la hagaajin karo ka dib hagaajinta, nidaaminta korantada iyo shaandhaynta isku xirka ; Kadib waxay gashaa buundada rogaha (qaybta ugu muhiimsan ee tamarta waxay isticmaashaa transistor MOSFET awood sare leh) waxayna isu beddeshaa xawli sare oo joogto ah, kaas oo loo isticmaali karo kuleyliyaha induction iyadoo la siinayo weelka xamuulka. Qaybta korantada rogashada waxay qabataa qaab-dhismeed modular ah, lammaane kasta oo ka mid ah unugyadu waxay soo saari karaan wax ka badan 50KW, tirada unugyada korantada ee la adeegsaday way kala duwan yihiin iyadoo ku xidhan awoodda qalabka. Weelku waa qaab is-bar-bar-is-bar-bar-dhig oo is-daba-joog ah, ma jiro danab sare, mana jiro wax-soo-saarka wax-soo-saarka.
